- Pulling capacity 55 kN (5,5 tons)
- Ideal for tractors 45 to 69 kW (60 - 95 hp)
- Automatic safety brake
- Mechanical control
- 3-point hitch as standard
- Weight 310 kg
- Logging plate width 1,50 meters
- Cableguard prevents derailment
- Radio control is optional
- Ratio 1:6
- Double clutch
Specifications
- Max pulling capacity / empty drum: 55 kN (5,5 tons)
- Max pulling capacity / full drum: 24 kN (2,4 tons)
- Number of drums: 1
- Wire rope, theoretical capacity: 128 m, 10 mm / 103 m, 11 mm / 85 m, 12 mm
- Recommended wire rope length: 50 m, 11 mm
- Pulling speed at 540 rpm: Without gear: 0,76 – 1,73 m/s, with gear 0,44 – 1,00 m/s
- Ratio: Without gear: 1:6, with gear: 1:10,36
- Necessary power input: Without gear: 45 kW, with gear 28 kW
- Braking power: Min 68,75 kN (6,88 tons)
- Controls: Standard cord operation
- Clutch: Double clutch with replaceable friction pads
- Brake: Automatic safety brake
- Mounting: 3-point hitch
- PTO input, distance from ground: 55 cm
- Height/ Width/ Depth: 158 / 150 / 58 cm
- Weight (without wire rope): 310 kg
