- Pulling capacity 60 kN (6 tons)
- Ideal for tractors 45 to 75 kW (60 - 100 hp)
- Automatic safety brake
- Mechanical control
- 3-point hitch as standard
- Weight 390 kg
- Logging plate width 1,73 meters
- Cableguard prevents derailment
- Radio control is optional
- Ratio 1:6
- Double clutch
- Adjustable height of pulling point
Specifications
- Max pulling capacity / empty drum: 60 kN (6 tons)
- Max pulling capacity / full drum: 26 kN (2,6 tons)
- Number of drums: 1
- Wire rope, theoretical capacity: 128 m, 10 mm / 103 m, 11 mm / 85 m, 12 mm
- Recommended wire rope length: 50 m, 11 mm
- Pulling speed at 540 rpm: Without gear: 0,76 – 1,73 m/s, with gear 0,44 – 1,00 m/s
- Ratio: Without gear: 1:6, with gear: 1:10,36
- Necessary power input: Without gear: 49 kW, with gear 31 kW
- Braking power: Min 75 kN (7,5 tons)
- Controls: Standard cord operation
- Clutch: Replaceable friction pads
- Brake: Automatic safety brake
- Mounting: 3-point hitch
- PTO input, distance from ground: 50 cm
- Height/ Width/ Depth: 198 / 173 / 70 cm
- Weight (without wire rope): 390 kg
